Maximum operating voltage（VAC） |
Operating frequency（Hz） |
Hipot test voltage P-N(VDC) 、PN-E(VAC) |
Operating temperatureHz |
Minimum insulation resistance |
380/440 |
50/60 |
2150（P-P，VDC）、2700（P-E，VDC） |
-25~+85℃ |
>200M@500VDC |
Product Model |
Connections - Bolts |
Current rating @40℃ |
Leakage current |
Components - L (mH) |
Components - Cx(μF) |
Components - Cy(nF) |
Components - R(MΩ) |
YB360-5 |
/M |
5A |
<0.5mA/p |
4.2 |
0.22 |
4.7 |
1 |
YB360-10 |
/M |
10A |
<0.5mA/p |
2.1 |
0.22 |
4.7 |
1 |
YB360-16 |
/M |
16A |
<0.5mA/p |
0.8 |
0.47 |
10 |
1 |
YB360-20 |
/M |
20A |
<0.5mA/p |
1.1 |
0.22 |
4.7 |
1 |
YB360-30 |
/M |
30A |
<1.0mA/p |
0.7 |
0.47 |
10 |
1 |
YB360-40 |
/M |
40A |
<1.0mA/p |
0.7 |
0.47 |
10 |
1 |
YB360-50 |
/M |
50A |
<1.0mA/p |
0.36 |
0.47 |
10 |
1 |
YB360-60 |
/M |
60A |
<1.0mA/p |
0.25 |
1 |
10 |
0.47 |
YB360-75 |
/M |
75A |
<1.0mA/p |
0.25 |
1 |
10 |
0.47 |
YB360-100 |
/M |
100A |
<1.0mA/p |
0.2 |
1 |
10 |
0.47 |
