High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)

High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks)

Get a Quote Contact Us
  • Description
product high quality single phase ac filters 1a 3a 6a 10a iec socket type with single insurance power system rfi lc rc networks-1

[email protected]
Inquiry
Product Description
Product Detail
Maximum operating voltage（VAC）
Operating frequency（Hz）
Hipot test voltage P-N(VDC) 、PN-E(VAC)
Operating temperature（℃）
Minimum insulation resistance
250
50/60
1500（P-N，VDC）、 1500（PN-E，VAC）
-25~+85
>200M@500VDC
Part No.
Current rating @40℃
Leakage current
Components - L (mH)
Components - Cx(μF)
Components - R(MΩ)
Components - Cy(nF)
Weight (g)
YB180-1
1A
≤ 0.3mA
5.5
0.1
1
2.2
50
YB180- 3
3A
≤ 0.3mA
3
0.1
1
2.2
50
YB180- 6
6A
≤ 0.3mA
1
0.1
1
2.2
50
YB180- 10
10A
≤ 0.3mA
0.4
0.1
1
2.2
50
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) factory
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) details
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) supplier
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) manufacture
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) supplier
Recommend Products
Company Profile
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) details
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) supplier
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) factory
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) manufacture
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) supplier
High Quality Single Phase AC Filters 1A 3A 6A 10A IEC Socket Type with Single Insurance Power System RFI (LC RC Networks) details
FAQ
Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
