Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems

Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems

Get a Quote Contact Us
  • Description
product industrial low leakage current single stage 3p4w emi power filter for cnc machines ups systems-1

[email protected]
Inquiry
Product Description
Product Detail
Maximum operating voltage（VAC）
Operating frequency（Hz）
Hipot test voltage P-N(VDC) 、PN-E(VAC)
Operating temperatureHz
Minimum insulation resistance
380V/440V/520V
50/60
2150（P-P，VDC）、2700（PN-E，VDC）、1760（P-N，VDC）
-25~+85℃
>200M@500VDC
Part No.
Connections - Bolts
Current rating @40℃
Leakage current
Components - L (mH)
Components - Cx(μF)
Components - Cy(nF)
Components - R(MΩ)
YB280-10
/M
10A
<2.2mA
1
0.22
4.7
1
YB280-20
/M
20A
<2.2mA
1
0.22
4.7
1
YB280-30
/M
30A
<2.2mA
0.4
0.47
4.7
1
YB280-50
/M
50A
<5.0mA
0.3
0.47
40
0.47
YB280-75
/M
75A
<10mA
0.25
0.47
100
0.47
YB280-100
/M
100A
<10mA
0.2
1
100
0.47
YB280-150
/M
150A
<25mA
0.18
1
235
0.47
YB280-200
/M
200A
<25mA
0.18
1
235
0.47
Industrial Low Leakage Current Single-Stage 3P4W EMI Power Filter for CNC Machines UPS Systems details
