Home > Products > Others > Filters > Power Filter
Maximum operating voltage（VAC） |
Operating frequency（Hz） |
Hipot test voltage P-N(VDC) 、PN-E(VAC) |
Operating temperatureHz |
Minimum insulation resistance |
250 |
50/60 |
1760（P-N，VDC）、2000（PN-E，VAC） |
-25~+85℃ |
>200M@500VDC |
Part No. |
Connections - Wire |
Connections - Bolts |
Connections - Solder |
Current rating @40℃ |
Leakage current |
Components - L (mH) |
Components - Cx(μF) |
Components - Cy(nF) |
Components - R(MΩ) |
YB210-1 |
/W |
---- |
---- |
1A |
< 0.3mA |
5.5 |
0.1 |
2.2 |
---- |
YB210-3 |
/W |
---- |
---- |
3A |
< 0.3mA |
2.5 |
0.1 |
2.2 |
---- |
YB210-6 |
/W |
---- |
---- |
6A |
< 0.3mA |
0.8 |
0.1 |
2.2 |
---- |
YB210-10 |
/W |
/M |
/L |
10A |
< 0.3mA |
1 |
0.22 |
2.2 |
1 |
YB210-20 |
---- |
/M |
/L |
20A |
< 0.3mA |
0.4 |
0.22 |
2.2 |
1 |
YB210-30 |
---- |
/M |
---- |
30A |
< 0.5mA |
0.3 |
0.22 |
4.7 |
1 |
YB210-40 |
---- |
/M |
---- |
40A |
< 0.5mA |
0.3 |
0.22 |
4.7 |
1 |
YB210-50 |
---- |
/M |
---- |
50A |
< 0.5mA |
0.2 |
0.47 |
4.7 |
1 |
YB210-75 |
---- |
/M |
---- |
75A |
< 1.0mA |
0.2 |
1 |
10 |
0.47 |
YB210-100 |
---- |
/M |
---- |
100A |
< 1.0mA |
0.18 |
2.2 |
10 |
0.47 |
YB210-150 |
---- |
/M |
---- |
150A |
< 5mA |
0.15 |
4.4 |
10 |
0.22 |
YB210-200 |
---- |
/M |
---- |
200A |
< 15mA |
0.15 |
13.2 |
100 |
0.22 |
