351-391MHz 5.5dBi Gain Vehicle-Mounted Omnidirectional Antenna for Tactical & Emergency Communications

351-391MHz 5.5dBi Gain Vehicle-Mounted Omnidirectional Antenna for Tactical & Emergency Communications

Description

[email protected]

Description

Product Description

1. Wide 360° Omnidirectional Coverage
Ensures consistent signal reception in all horizontal directions, ideal for mobile operations in dynamic environments.

2. High 100W Power Handling
Supports high-power transmission for reliable long-range communication even in demanding scenarios.

3. Rugged & Compact Vehicle-Mounted Design
Built with an integrated M110 base and total height of 847mm, offering durability and easy installation on various vehicle types.

4. Optimized for Tactical & Emergency Use
Operates in the 351-391MHz band, making it suitable for military, public safety, and professional mobile radio applications.

5. Broad Operating Temperature Range
Functions reliably in extreme conditions from -40°C to +60°C, ensuring performance in harsh climates and environments.

Product Detail

Electrical Indicators
Frequency Range - MHz	351 ~ 391
Bandwidth - MHz	40
Polarization Mode	Vertical
Voltage Standing Wave Ratio	≤2.0
Gain - dBi	5.5
Horizontal 3dB Beamwidth (°)	360
Vertical 3dB Beamwidth (°)	30
Maximum Power - W	100
Input Impedance - Ω	50
Ground Protection	DC
Mechanical Parameters
Connector Type (Cable End)	N - J
Cable Specification	SYV - 50 - 3
Cable Length - m	3
Operating Temperature - °C	- 40 ~ +60
Antenna Height (Including M110 Base, mm)	847
Antenna Weight (Including M110 Base, g)	760
