356-368MHz 4dBi Gain Portable Omnidirectional Antenna for Field Use

356-368MHz 4dBi Gain Portable Omnidirectional Antenna for Field Use

Description

[email protected]

Description

Product Description

1. Lightweight & Portable Design
Weighing ≤1kg with a compact 880mm length, this antenna is specifically designed for easy carrying and rapid deployment in field operations.

2. Military-Grade Environmental Durability
Meets GJB367A standards for vibration, shock, salt spray, damp heat, rain and atmospheric pressure, ensuring reliable performance in extreme conditions.

3. True 360° Omnidirectional Coverage
Provides consistent all-around horizontal coverage, maintaining communication reliability regardless of operator movement or antenna orientation.

4. Wide Operating Temperature Range
Functions reliably in temperatures from -40°C to +60°C, suitable for use in virtually all climate conditions from arctic to desert environments.

5. Quick-Connect N-Type Interface
Features a reliable N-J connector for secure attachment to communication equipment, enabling fast setup and teardown in time-critical situations.

Product Detail

Electrical Indicators
Name	Portable Antenna
Frequency (MHz)	356 - 368
Polarization Mode	Vertical
Gain (dBi)	4
Horizontal 3dB Beamwidth	360°
Vertical 3dB Beamwidth	> 30°
Voltage Standing Wave Ratio	≤2.0
Maximum Power (W)	50
Input Impedance (Ω)	50
Mechanical Indicators
Connector Type	N - J
Antenna Dimension (mm)	Φ19*880±10 (see schematic diagram for details)
Antenna Weight (kg)	≤1
Limit Wind Speed (m/s)	60
Antenna Color	Olive drab GY05
Installation Method	Direct connection to equipment
Environmental Indicators
Operating Temperature (°C)	- 40~+60
Storage Temperature (°C)	-45~+70
Vibration	GJB367A - 2001 3.10.3.1
Shock	GJB367A - 2001 3.10.3.2
Salt Spray	GJB367A - 2001 3.10.2.14
Damp Heat	GJB367A - 2001 3.10.2.5
Rain	GJB367A - 2001 3.10.2.7
Atmospheric Pressure	GJB367A - 2001 3.10.2.3
