360° Omnidirectional 4dBi Gain 356-368MHz Professional Vehicle-Mounted Antenna

360° Omnidirectional 4dBi Gain 356-368MHz Professional Vehicle-Mounted Antenna

Description

[email protected]

Description

Product Description

1. Excellent Signal Efficiency with Low VSWR
Features an outstanding voltage standing wave ratio of <1.5, ensuring maximum power transfer and superior signal quality with minimal reflection loss.

2. True 360° Omnidirectional Coverage
Provides consistent all-around horizontal signal reception, maintaining reliable communication regardless of vehicle direction or position.

3. Optimized Vertical Beamwidth
With a vertical beamwidth >40°, offers excellent coverage for both short-range and medium-distance communications in mobile environments.

4. Professional N-Type Connector
Equipped with a reliable N-J connector, ensuring secure and stable connection suitable for professional mobile communication systems.

5. Rugged Construction for Harsh Conditions
Built to withstand extreme temperatures from -40°C to +60°C, featuring DC lightning protection for reliable operation in all weather conditions.

Product Detail

Electrical Indicators
Model	YW - 40VPG4 - 360 - C
Frequency Range - MHz	356 ~ 368
Bandwidth - MHz	12
Polarization Mode	Vertical
Voltage Standing Wave Ratio	< 1.5
Gain - dBi	4
Horizontal Half - Power Beamwidth (°)	360
Vertical Half - Power Beamwidth (°)	> 40
Maximum Power - W	50
Input Impedance - Ω	50
Lightning Protection	DC Grounding
Mechanical Indicators
Connector Type (Cable End)	N - J
Operating Temperature - ℃	- 40 ~ +60
Cable Specification	SYV - 50 - 3
Cable Length - m	3
Antenna Height (Including M90 Base, mm)	920±20

Recommend Products

Company Profile

product 360 omnidirectional 4dbi gain 356 368mhz professional vehicle mounted antenna-2

product 360 omnidirectional 4dbi gain 356 368mhz professional vehicle mounted antenna-3

product 360 omnidirectional 4dbi gain 356 368mhz professional vehicle mounted antenna-4

product 360 omnidirectional 4dbi gain 356 368mhz professional vehicle mounted antenna-5

product 360 omnidirectional 4dbi gain 356 368mhz professional vehicle mounted antenna-6

product 360 omnidirectional 4dbi gain 356 368mhz professional vehicle mounted antenna-7

FAQ

Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
