YWDSPXD698-4000V-2W-5i-N-F |
||||||
Frequency range (MHz) |
698-960 |
1710-2700 |
3300-4000 |
|||
Polarization |
Vertical |
|||||
Gain(dBi) |
2 |
5 |
5.5 |
|||
Horizontal beam-width(°) |
360 |
|||||
3dB Vertical beam-width(°) |
85 |
50 |
40 |
|||
VSWR |
≤1.5 |
≤1.5 |
≤1.8 |
|||
Intermodulation IM3(dBc) |
≤-150dBc(@2*33dBm) |
|||||
Impedance(Ω) |
50 |
|||||
Maximum input power(W) |
50 |
|||||
Lightning protection |
DC grounded |
|||||
Connector |
1×N-Female |
|||||
Connector position |
Bottom |
|||||
Size(mm) |
Φ186 x 83 |
|||||
weight(kg) |
0.28 |
|||||
Radome material |
ABS |
|||||
Radome color |
White |
|||||
Operating temperature(℃) |
-40～65 |
|||||
Mounting Kit |
On-wall |
|||||
