Yoongwin
Introducing the Yoongwin Dual-Band Vehicle Roof Mounted Antenna, the perfect solution for enhancing your GPS and GNSS signal strength while on the go. This antenna is designed to operate within the 2400-2500MHz and 5150-5850MHz frequencies, ensuring reliable connectivity no matter where your travels take you.
With vertical polarization, this antenna can effectively capture signals from satellites and other sources, allowing you to maintain precise positioning and communication even in challenging environments. Whether you are navigating through urban jungles or Yoongwin remote wilderness, the Yoongwin Dual-Band Antenna will keep you connected.
The sleek and durable design of this antenna makes it perfect for mounting on your vehicle's roof. It is weather-resistant and built to withstand the rigors of travel, ensuring that you can rely on it for years to come. Installation is quick and easy, and once in place, the antenna will provide you with improved signal strength and accuracy in your GPS and GNSS navigation systems.
One of the standout features of the Yoongwin Dual-Band Antenna is its 5G compatibility. With the ability to connect to emerging 5G networks, this antenna future-proofs your setup and ensures that you can take full advantage of the latest technological advancements in connectivity.
Whether you are a frequent traveler, a commercial driver, or simply someone who values reliable GPS and GNSS performance, the Yoongwin Dual-Band Vehicle Roof Mounted Antenna is an essential addition to your vehicle. Say goodbye to lost signals and inaccurate positioning with this antenna, you can travel with confidence and peace of mind.
Don't settle for subpar antenna performance. Upgrade to the Yoongwin Dual-Band Vehicle Roof Mounted Antenna and experience the difference that high-quality signal reception can make. Stay connected, stay on course, and stay ahead of the curve with Yoongwin
Technical Indicators |
QC2458SC |
||
Frequency Range (MHz) |
2400 - 2500 |
5150 - 5850 |
|
Polarization Mode |
Vertical |
||
Antenna Gain (dBi) |
2 (Excluding Cable Loss) |
||
Voltage Standing Wave Ratio |
≤2 |
||
Input Impedance (Ω) |
50 |
||
Connector Type |
Shock - proof TNCJ |
||
Antenna Dimensions (mm) |
Φ75×68 |
||
Cable Type |
LMR200 Multi core Cable |
||
Cable Length (m) |
5 |
||
Antenna Weight (kg) |
Approx. 0.43 |
||
Housing Material |
ABS (Black) |
||
Maximum Wind Speed (m/s) |
35 |
||
Operating Temperature (°C) |
-40 ~ 75 |
||
Storage Temperature (°C) |
-55 ~ 85 |
||
Mounting Method |
Magnetic Adsorption |
||
Mounting Method |
Magnetic Adsorption |
||
Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years.
Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples.
Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay, Paypal, Afterpay, Klarna etc.
Q: What certifications do you have? A: Certified by FCC, CE, RoHS, ISO available upon request.
Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
