FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M
FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M

FiberHome CE Certified IP67 3.8Gbps Sub-6G Dual Mode NSA/SA 5G Outdoor Cpe Router with 2.5GE Port TR069 Smart O&M

Get a Quote Contact Us
  • Description
sa 5g outdoor cpe router with 25ge port tr069 smart om-1

[email protected]
Inquiry
Product Description
Product Detail
Physical Parameter
Size
230*140*36mm
Weight
About 840g
Color
White
Operating Temperature
-40℃~55℃ without solar radiation
Power Consumption
< 14.4W
Power Supply
DC 48V, 0.3A
NNI Ports
5G NR/4G LTE
UNI Ports
1*2.5GE
Memory
1GB DDR , 1GB Flash
LED Indicators
Power, 5G NR, 4G LTE
Power Supply Mode
PoE
Level of Dustproof and
Waterproof
IP67

RF Interface

5G NR
* Support 5G NR (3GPP Release 15) Sub-6G
* 5G NR Bands: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78
* 5G DL 4*4 MIMO: n1/n3/n7/n38/n40/n41/n77/n78
* Peak Throughput: DL 3.8Gbps/UL 2.5Gbps
4G LTE
* LTE Category: Cat 19
* Support TDD-LTE/FDD-LTE
* 4G FDD Bands: B1/B3/B5/B7/B8/B20/B28/B32
* 4G TDD Bands: B38/B40/B41/B42/B43
* 4G DL 4*4 MIMO: B1/B3/B7/38/B40/B41/B42/B43
* Peak Throughput: DL 1.6Gbps/UL 316Mbps
RF Extensions
* Support NR 2CC CA
* Support ENDC
* Support DSS
SIM Slot
* 4FF SIM Card (Nano-SIM) format
* Support carrier SIM lock
* Support SIM card hot swap

UNI Interface
Ethernet Port
* 1*2.5GE for LAN port
* RJ45 interface
* 10M/100M/1000M/2500M autonegotiation
* MDI/MDIX auto-sensing
* IEEE 802.3/802.3u

Wi-Fi Interface
* IEEE 802.11 b/g/n/ax 2.4G , used for management
purpose only
* 1 Built-in 2.4G Wi-Fi antennas


Product Function
Smart Interconnection
* Easy to access two network: 5G/4G LTE
* Support two 5G network mode: NSA/SA
* Easy to connect to ACS by TR069
* IPv4/IPv6 auto-negotiation
* Different LED clearly indicate network status
Software Update
* Web UI update
* TR069 update
* FOTA update
Device Management
* Web UI
* TR069 management
APN Setting
* Support default APN (customized)
* Set APN username/password/IP mode
Security Services
* Firewall service: firewall switch, DMZ, UPnP, port forwarding, IP MAC binding
* ACL filter: Mac/IP address filter, Port/URL filter
L3 Functions
* Support DHCP/Static IP config
* Support IPv4, IPv6, IPv4/IPv6 dual stack
* DNS RELAY and NAT
* ALG: L2TP/IPSEC/SIP FTP
* Support PPTP/L2TP VPN/IPSec VPN
