Enhance your vehicle's signal reception with the High 5dBi Gain Vehicle Omnidirectional Patch Antenna from Yoongwin. Designed for optimal performance, this antenna features a full frequency range of 2400-2500MHz and vertical polarization, ensuring a strong and stable connection in any driving conditions.
With a 5dBi gain, this antenna boosts the signal strength, allowing you to stay connected even in remote areas or areas with poor reception. Whether you're streaming music, making calls, or using GPS navigation, this antenna will ensure that you have a fast and reliable connection at all times.
The omnidirectional design of this antenna means that it can receive signals from all directions, making it ideal for use in vehicles where the antenna may be moving or changing directions frequently. This ensures that you always have a strong and consistent signal, no matter where you are driving.
Installation of this antenna is quick and easy, thanks to its magnetic base and adhesive pad. Simply attach the antenna to the roof of your vehicle and connect it to your device using the included cable. The compact size of the antenna also makes it discreet and unobtrusive, so it won't clutter up your vehicle's exterior.
Made from high-quality materials, this antenna is built to last and withstand the rigors of daily use. Its durable construction ensures that it can withstand harsh weather conditions, vibrations, and other challenges that may arise while driving.
The High 5dBi Gain Vehicle Omnidirectional Patch Antenna from Yoongwin is a reliable and efficient solution for improving signal reception in your vehicle. With its high gain, wide frequency range, and easy installation, this antenna is the perfect upgrade for any driver looking to stay connected on the road. Say goodbye to dropped calls and slow data speeds - with this antenna, you'll always have a strong and stable connection wherever you go
Technical Indicators |
QC2400E |
Frequency Range (MHz) |
2400 ~ 2500 |
Bandwidth (MHz) |
100 |
Polarization Mode |
Vertical |
Gain (dBi) |
5 |
Input Impedance (Ω) |
50 |
Voltage Standing Wave Ratio |
≤2 |
Maximum Power (W) |
50 |
Connector Type |
SMA Male or as specified by user |
Antenna Dimensions (mm) |
116×21×5 |
Cable Length (m) |
3 or as specified by user |
Antenna Weight - kg |
Approx. 0.05 |
Mounting Method |
Double - sided Adhesive |
Q: Are you a manufacturer or a trading company
A: We have been professional antenna manufacturer for 18 years
Q: Have gps gsm combo antenna 100% assembles well in stock
A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples
Q: Could I use my own LOGO or design on goods
A: Yes, customized logo and design on mass production are available
Q: What's the payment term
A: T/T, AliPay, Paypal, Afterpay, Klarna etc
Q: What certifications do you have
A: Certified by FCC, CE, RoHS, ISO available upon request
Q: Where is your factory located? Can I visit your factory
A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province
Just call us, we will pick you up with no delay
