Channel |
CH1 |
CH2 |
CH3 |
||
Frequency Range (MHz) |
1730 - 1880 |
1920 - 2170 |
3300 - 3700 |
||
Insertion Loss (dB) |
≤0.6 |
||||
In - band Ripple (dB) |
≤0.5 |
||||
Port Isolation (dB) |
≥80 |
||||
VSWR |
≤1.3 |
||||
Impedance (Ω) |
50 |
||||
Third - order Intermodulation (dBc) |
≤ - 150@43dBm×2 |
||||
Fifth - order Intermodulation (dBc) |
≤ - 165@43dBm×2 |
||||
Interface Type |
DIN - F |
||||
Power Capacity (W) |
Average Power Capacity ≥500, Peak Power Capacity ≥1500 |
||||
Dimension（mm） |
186*134*33.5 |
||||
