Product Name |
Directional Panel Antenna |
|
Electrical Index |
DB58-65V15A |
|
Frequency Range (MHz) |
5150～5850 |
|
Polarization |
Vertical |
|
Gain (dBi) |
15 |
|
Electrical Down-tilt (°) |
0 |
|
Half-power Beamwidth (°) |
Horizontal: 65 |
|
Vertical: 15 |
||
First Upper Side-lobe Suppression (dB) |
/ |
|
Front-to-Back Ratio (dB) |
≥23 |
|
Input Impedance (Ω) |
50 |
|
Voltage Standing Wave Ratio (VSWR) |
≤2 |
|
Maximum Power (W) |
50 |
|
Lightning Protection |
DC Ground |
|
Mechanical & Environmental Index |
||
Connector Type |
N Female |
|
Connector Position |
Bottom |
|
Antenna Dimensions (L×W×H: mm) |
230×128×56 |
|
Packaging Dimensions (mm) |
330×230×160 |
|
Antenna Weight (kg) |
1 |
|
Radome Material |
UPVC |
|
Radome Color |
Gray |
|
Mechanical Adjustable Tilt (°) |
0～15 |
|
Operating Temperature (℃) |
-40～60 |
|
Ultimate Wind Speed (m/s) |
60 |
|
Mast Diameter (mm) |
35～75 |
|
Mounting Part Model |
MK003 |
|
