Electrical Specifications |
||||||||||
Operating Frequency Band (MHz) |
1710~1830 |
1885~1915 |
2010~2025 |
2300~2400 |
2515~2675 |
|||||
Polarization (°) |
±45° |
|||||||||
Voltage Standing Wave Ratio (VSWR) of Each Radiating Port |
≤1.5 |
|||||||||
Third-Order Intermodulation (dBm, @2×37 dBm) |
≤-107 |
/ |
/ |
/ |
/ |
|||||
Average Power Handling Capacity (W) |
≥50 |
|||||||||
Isolation (dB) |
≥25 |
|||||||||
Horizontal Half-Power Beamwidth (°) |
≥60 |
|||||||||
Vertical Half-Power Beamwidth (°) |
[20, 35] |
|||||||||
Gain (dBi) |
≥12 |
|||||||||
Cross-Polarization Ratio in Vertical 3dB Beamwidth (dB) |
≥10 |
|||||||||
Cross-Polarization Ratio in Horizontal 3dB Beamwidth (dB) |
≥10 |
|||||||||
Front-to-Back Ratio (dB) |
≥23 |
|||||||||
Mechanical Specifications |
||||||||||
Interface Model |
2×N-Female (Lead Length ≥200 mm, Lead Outer Diameter ≥5 mm) |
|||||||||
Antenna Dimensions (mm) |
430×430×150 |
|||||||||
Packaging Dimensions (mm) |
475×460×160 |
|||||||||
Antenna Weight (kg) |
2.7 |
|||||||||
Weight of Mounting Accessories (kg) |
0.9 |
|||||||||
Radome Material |
Weather-Resistant PP (Polypropylene) |
|||||||||
Adjustable Range of Mechanical Angle (°) |
Horizontal: ±45 (Triangular Bracket Required); Vertical: -30~+70 |
|||||||||
Maximum Wind Speed (km/h) |
200 |
|||||||||
Ambient Temperature (°C) |
Operating Temperature (°C): -40~+70; Extreme Temperature: -55~+75 |
|||||||||
Lightning Protection |
DC Grounding |
|||||||||
