N-Type Female Connector 360° Coverage 6dBi Gain 1420-1530MHz L-Band Omnidirectional Antenna

N-Type Female Connector 360° Coverage 6dBi Gain 1420-1530MHz L-Band Omnidirectional Antenna

Description

[email protected]

Description

Product Description

1.Dedicated L-Band Operation (1420-1530MHz): Specifically engineered for satellite and specialized communication applications.Delivers reliable ≥6dBi gain performance with complete 360° omnidirectional coverage for uninterrupted connectivity.

2.True Omnidirectional Performance: 360° horizontal coverage ensures consistent signal reception from all directions without antenna realignment. Ideal for applications requiring stable connectivity regardless of orientation changes.

3Built for Harsh Environments: Withstands extreme temperatures from -40℃ to +85℃ and features salt spray corrosion resistance.Ensures reliable performance in coastal, desert, and high-altitude applications.

4.Lightweight Professional Construction: At only 1.0kg with a compact 1.0m profile, this antenna offers easy installation without compromising durability. Perfect for mobile and fixed station applications alike.

5.High-Power 100W Capacity: Professional N-Type female connector supports high-power transmission up to 100W. Designed for critical communication systems where signal integrity and power handling are paramount.

Product Detail

Electrical Properties
Frequency Range	1420～1530 MHz
Impedance	50 Ω
Polarization	Vertical Polarization
Beamwidth	Horizontal: 360°; Elevation: ＞16°
Voltage Standing Wave Ratio (VSWR)	≤2.5
Antenna Gain	≥6 dBi
Maximum Power	100 W
Connector Type	N-Type Female Connector
Operating Environment
Operating Temperature	-40℃～+85℃
Storage Temperature	-55℃～+85℃
Humidity	95% (non-condensing)
Special Protection	Salt Spray Corrosion Resistance
Structural Dimensions
Antenna Length	1.0 m
Antenna Weight	1.0 Kg
