Suction Cup Base Magnetic Mount Omnidirectional Antenna for Portable Temporary Communications

Suction Cup Base Magnetic Mount Omnidirectional Antenna for Portable Temporary Communications

Description

[email protected]

Description

Product Description

1. Quick Installation with Magnetic Mount
Features a powerful M62 suction cup base for instant deployment on any metal surface, eliminating the need for drilling or permanent installation.

2. True 360° Omnidirectional Coverage
Provides consistent all-around signal reception, ensuring reliable communication regardless of antenna orientation.

3. Complete Ready-to-Use Package
Comes with a built-in 3-meter cable and SMA-J connector, making it immediately operational out of the box.

4. Lightweight and Portable Design
Weighing only 0.2kg with a compact 292mm height, this antenna is ideal for mobile use and easy storage.

5. Wide Temperature Tolerance
Operates reliably in extreme temperatures from -40°C to +70°C, suitable for use in virtually all environmental conditions.

Product Detail

Electrical Indicators
Frequency Range - MHz	223 ~ 235
Polarization Mode	Vertical
Voltage Standing Wave Ratio	≤1.5
Gain - dBi	1.8
Electrical Downtilt Angle (°)	0
Horizontal Half - Power Beamwidth (°)	360
Maximum Power - W	100
Input Impedance - Ω	50
Mechanical Indicators
Connector Type	SMA - J
Connector Position	Bottom Lead - out
Lead - out Cable Length (m)	3
Antenna Dimension (Including Suction Cup Base) - mm	292
Antenna Weight (Including Suction Cup Base) - kg	0.2
Radome Color	Black
Operating Temperature (°C)	- 40 ~ +70
Installation Method	Magnetic Adsorption
Remarks: Equipped with M62 suction cup base, lead - out cable length is 3m.

Recommend Products

Company Profile

product suction cup base magnetic mount omnidirectional antenna for portable temporary communications-2

product suction cup base magnetic mount omnidirectional antenna for portable temporary communications-3

product suction cup base magnetic mount omnidirectional antenna for portable temporary communications-4

product suction cup base magnetic mount omnidirectional antenna for portable temporary communications-5

product suction cup base magnetic mount omnidirectional antenna for portable temporary communications-6

product suction cup base magnetic mount omnidirectional antenna for portable temporary communications-7

FAQ

Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
