UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor

UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor

Get a Quote Contact Us
  • Description
product ul 508 certified 220v 3a 5a 10a 12a 15a 20a 25a 30a 40a 50a 60a 80a 100a single phase ac line reactor-1

[email protected]
Inquiry
Product Description
Product Detail
Rated voltage
220V/50HZ
Rated current
3A~300A
Insulation resistance
>100MΩ
Noise level
<65dB
Protection level
IP00
Dielectric strength
Core to winding 3500VAC/50HZ/10MA/10S no arc breakdown
Execution standard
GB10229 - 88 Reactor/JB9644 - 1999 Reactor for semiconductor electric
REACTOR MODEL
RATED CURRENT
(A)
PRESSURE DROP
(V)
INDUCTOR
(mH)
YBDK-3-4.67
3
4.4
4.67
YBDK-5-2.8
5
4.4
2.8
YBDK-10-1.4
10
4.4
1.4
YBDK-12-1.167
12
4.4
1.167
YBDK-15-0.934
15
4.4
0.934
YBDK-20-0.7
20
4.4
0.7
YBDK-25-0.56
25
4.4
0.56
YBDK-30-0.467
30
4.4
0.467
YBDK-40-0.35
40
4.4
0.35
YBDK-50-0.28
50
4.4
0.28
YBDK-60-0.233
60
4.4
0.233
YBDK-80-0.175
80
4.4
0.175
YBDK-100-0.127
100
4.4
0.14
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor details
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor manufacture
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor factory
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor details
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor details
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor details
Recommend Products
Company Profile
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor manufacture
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor factory
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor details
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor manufacture
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor manufacture
UL 508 Certified 220V 3A 5A 10A 12A 15A 20A 25A 30A 40A 50A 60A 80A 100A Single-phase AC Line Reactor details
FAQ
Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
