Channel |
CH1 |
CH2 |
CH3 |
CH4 |
|||
Frequency Range (MHz) |
820 - 960 |
1730 - 1880 |
1920 - 2170 |
3300 - 3700 |
|||
Insertion Loss (dB) |
≤0.6 |
||||||
In - band Ripple (dB) |
≤0.5 |
||||||
Port Isolation (dB) |
≥80 |
||||||
VSWR |
≤1.3 |
||||||
Impedance (Ω) |
50 |
||||||
Third - order Intermodulation (dBc) |
≤ - 145@43dBm×2 |
||||||
Fifth - order Intermodulation (dBc) |
≤ - 160@43dBm×2 |
||||||
Interface Type |
N - F |
||||||
Power Capacity (W) |
Average Power Capacity ≥300, Peak Power Capacity ≥1200 |
||||||
Dimension（mm） |
186*135*33.5 |
||||||
