Technical Indicators |
YW-QE2458B |
||
Frequency Range (MHz) |
2400～2500 |
5150～5850 |
|
Bandwidth (MHz) |
100 |
700 |
|
Polarization Mode |
Vertical |
||
Gain (dBi) |
3 |
4 |
|
Input Impedance (Ω) |
50 |
||
Voltage Standing Wave Ratio |
≤2 |
||
Maximum Power (W) |
20 |
||
Connector Type |
N Female or Customized by User |
||
Antenna Size (mm) |
φ165×94 |
||
Lead Length (cm) |
30 |
||
Antenna Color |
White |
||
Antenna Weight (kg) |
0.3 |
||
Mounting Method |
Ceiling Mounted |
||
Antenna Weight (kg) |
0.3 |
||
Mounting Method |
Ceiling Mounted |
||
