Home > Products > Others > Filters > Power Filter
| Model | Rated Current (A) |
Ground Capacitance (nF) |
Leakage Current (mA) |
Discharge Resistance (MΩ) |
| DL-3D1 | 3 | 3.3 | ≤0.5 | - |
| DL-3D3 | 3 | 3.3 | 0.5 | - |
| DL-6D1 | 6 | 3.3 | 0.5 | - |
| DL-6D3 | 6 | 3.3 | 0.5 | - |
| DL-10D | 10 | 3.3 | 0.5 | 1.5 |
| DL-20D1 | 20 | 3.3 | 0.5 | 1.5 |
| DL-20D3 | 20 | 3.3 | 0.5 | 1.5 |
| DL-30D1 | 30 | 3.3 | 0.5 | 1.5 |
| DL-50D3 | 50 | 4.7 | 0.8 | 1.5 |
| DL-60D3 | 60 | 4.7 | 0.8 | 1.5 |
| DL-100D3 | 100 | 6.8 | 1 | 1.5 |
| DL-120D3 | 120 | 6.8 | 1 | 1.5 |
