| Rated Voltage | 250VAC | |||
| Operating Frequency | 50/60Hz | |||
| Rated Current | 3A - 10A | |||
| Test Voltage (1min) | 1500VDC (line/line); 1500VAC (line/ground) | |||
| Climatic Category | 25/085/21 |
| Model |
Rated Current （A） |
Ground Capacitance（nF） |
Leakage Current ≤（mA） |
Discharge Resistance（MΩ） |
| DL - 3DZ2R | 3 | 2.2 | 0.5 | 1 |
| DL - 6DZ2R | 6 | 2.2 | 0.5 | 1 |
| DL - 10DZ2R | 10 | 2.2 | 0.5 | 1 |
| DL - 3DZ2KR | 3 | 2.2 | 0.5 | 1 |
| DL - 6DZ2KR | 6 | 2.2 | 0.5 | 1 |
| DL - 10DZ2KR | 10 | 2.2 | 0.5 | 1 |
| DL - 3DZ2KR2 | 3 | 2.2 | 0.5 | 1 |
| DL - 6DZ2KR2 | 6 | 2.2 | 0.5 | 1 |
| DL - 10DZ2KR2 | 10 | 3.3 | 0.5 | - |
