Home > Products > Others > Filters > Power Filter
| Rated Voltage | 440/250VAC |
| Operating Frequency | 50 - 60Hz |
| Rated Current | 10A - 35A |
| Test Voltage (1 min) | 1500 VDC (line/line); 2250 VDC (line/ground) |
| Climatic Category | 40/085/21 |
| Model |
Rated Current （A） |
Ground Capacitance（nF） | Discharge Resistance（KΩ） |
| DL - 5EAT1 | 5 | 47 | 440 |
| DL - 10EAT1 | 10 | 47 | 440 |
| DL - 20EAT1 | 20 | 47 | 440 |
| DL - 25EAT1 | 25 | 47 | 440 |
| DL - 35EAT1 | 35 | 47 | 440 |
