| Rated Voltage | 250VDC | |||
| Rated Current | 2A - 10A | |||
| Test Voltage (1min) | 500VDC (line/ground) | |||
| Climatic Category | 25/085/21 |
| Model |
Rated Current （A） |
Ground Capacitance（nF） |
Leakage Current ≤（mA） |
Discharge Resistance（MΩ） |
| DL - 2FPC | 2 | 2.2 | - | - |
| DL - 3FPC | 3 | 33 | - | - |
| DL - 6FPC | 6 | 22 | - | - |
| DL - 10FPC | 10 | 33 | - | - |
