| Electrical Index | DB58-60V18A |
| Frequency Range (MHz) | 5725～5850 |
| Polarization | Vertical |
| Gain (dBi) | 18 |
| Electrical Down-tilt (°) | 0 |
| Half-power Beamwidth (°) | Horizontal: 60 |
| Vertical: 6.5 | |
| First Upper Side-lobe Suppression (dB) | / |
| Front-to-Back Ratio (dB) | ≥25 |
| Input Impedance (Ω) | 50 |
| Voltage Standing Wave Ratio (VSWR) | ≤1.5 |
| Maximum Power (W) | 50 |
| Lightning Protection | DC Ground |
| Mechanical & Environmental Index | |
| Connector Type | N Female |
| Connector Position | Bottom |
| Antenna Dimensions (L×W×H: mm) | 500×128×56 |
| Packaging Dimensions (mm) | 500×230×160 |
| Antenna Weight (kg) | 1.3 |
| Radome Material | UPVC |
| Radome Color | Gray |
| Mechanical Adjustable Tilt (°) | 0～15 |
| Operating Temperature (℃) | -40～60 |
| Ultimate Wind Speed (m/s) | 60 |
| Mast Diameter (mm) | 35～75 |
| Mounting Part Model | MK003 |
