Electrical Indicators |
||||
Operating Frequency Band (MHz) |
2400MHz - 2500MHz |
5150MHz - 5850MHz |
||
Polarization Mode |
Vertical (for both bands) |
Vertical (for both bands) |
||
Gain (dBi) |
8 |
10 |
||
Horizontal Half - Power Beamwidth (°) |
360 |
|||
Vertical Half - Power Beamwidth (°) |
22 |
11 |
||
Voltage Standing Wave Ratio |
≤1.5 |
≤2 |
||
Average Power Capacity (W) |
≥50 (for both bands) |
|||
Mechanical Indicators |
||||
Interface Model |
2×N - Female |
|||
Antenna Dimension (mm) |
Φ75×465 |
|||
Packaging Dimension (mm) |
160×160×560 |
|||
Antenna Weight (kg) |
1.3kg (≤1.5) |
|||
Radome Material |
UPVC (White) |
|||
Pole Diameter (mm) |
Φ40 ~ Φ90 |
|||
Limit Wind Speed (km/h) |
200 |
|||
Ambient Temperature (°C) |
Operating temperature: - 40 ~ +60; Limit temperature: - 55 ~ +75 |
|||
Lightning Protection |
DC Grounding |
|||
