3200mm Fiberglass 360° Coverage 8dBi 440-480MHz UHF High Gain Omnidirectional Antenna

3200mm Fiberglass 360° Coverage 8dBi 440-480MHz UHF High Gain Omnidirectional Antenna

Description

[email protected]

Description

Product Description

1.Optimized 440-480MHz UHF Band Performance: Delivers superior 8dBi gain with excellent signal penetration. Ideal for industrial complexes and urban environments where reliable communication through obstacles is critical.

2.Precision 17° Vertical Beamwidth: Combines true 360° horizontal coverage with focused vertical signal concentration. Provides longer communication range and reduced interference compared to standard omnidirectional antennas.

3.Professional Base Station Design: 3200mm fiberglass structure built for permanent installation. Withstands 36.9m/s wind loads and operates reliably in temperatures from -40℃ to +60℃ for year-round performance.

4.High-Power 100W Capacity: Supports extended-range communications with clear signal quality. Professional N-K connector ensures secure, weather-resistant connections for critical communication systems.

5.Industrial-Grade Environmental Protection: FRP radome provides excellent resistance to humidity, UV radiation, and corrosion.Maintains stable performance in harsh industrial environments with <95% humidity tolerance.

Product Detail

Electrical Performance
Frequency Range (MHz)	440～480
Gain (dBi)	8
Horizontal Beamwidth	360°
Vertical Beamwidth	17°
Voltage Standing Wave Ratio (VSWR)	≤1.5
Impedance	50 Ω
Polarization	Vertical Polarization (V)
Maximum Power (Max. Power)	100 W
Connector Type	N-K
Lightning Protection	DC Grounding
Mechanical & Environmental Specifications
Dimension (mm)	3200
Weight (kg)	2 kg
Rated Wind Velocity (Wind Resistance)	36.9 m/s
Operational Humidity	< 95%
Operating Temperature	-40～+60 ℃
Radome Material	Fiberglass Reinforced Plastic (FRP)
Suitable Pole Diameter	φ40～50 mm

Recommend Products

Company Profile

product 3200mm fiberglass 360 coverage 8dbi 440 480mhz uhf high gain omnidirectional antenna-2

product 3200mm fiberglass 360 coverage 8dbi 440 480mhz uhf high gain omnidirectional antenna-3

product 3200mm fiberglass 360 coverage 8dbi 440 480mhz uhf high gain omnidirectional antenna-4

product 3200mm fiberglass 360 coverage 8dbi 440 480mhz uhf high gain omnidirectional antenna-5

product 3200mm fiberglass 360 coverage 8dbi 440 480mhz uhf high gain omnidirectional antenna-6

product 3200mm fiberglass 360 coverage 8dbi 440 480mhz uhf high gain omnidirectional antenna-7

FAQ

Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
