360° Omnidirectional 5.5dBi Gain 350-390MHz Vehicle-Mounted Tactical Antenna for Public Safety Vehicles

360° Omnidirectional 5.5dBi Gain 350-390MHz Vehicle-Mounted Tactical Antenna for Public Safety Vehicles

Description

[email protected]

Description

Product Description

1. True 360° Omnidirectional Coverage
Provides consistent all-around signal reception, essential for reliable communication in mobile and tactical environments.

2. High Power Handling for Demanding Use
Supports up to 100W transmission power, ensuring strong and stable long-range communication under high-load conditions.

3. BNC Connector for Quick & Secure Installation
Equipped with a standard BNC-J connector for easy, tool-free setup and compatibility with a wide range of radio devices.

4. Rugged Design for Vehicle Deployment
Compact and durable construction (847mm height, 760g) with an integrated M110 base, built to withstand vibration and harsh outdoor use.

5. Wide Operating Temperature Range
Reliable performance in extreme temperatures from -40°C to +60°C, making it suitable for use in varied and challenging climates.

Product Detail

Electrical Indicators
Frequency Range - MHz	350 ~ 390
Bandwidth - MHz	40
Polarization Mode	Vertical
Voltage Standing Wave Ratio	≤2.0
Gain - dBi	5.5
Horizontal 3dB Beamwidth (°)	360
Vertical 3dB Beamwidth (°)	30
Maximum Power - W	100
Input Impedance - Ω	50
Ground Protection	DC
Mechanical Parameters
Connector Type (Cable End)	BNC - J
Cable Specification	SYV - 50 - 3
Cable Length - m	3
Operating Temperature - °C	- 40 ~ +60
Antenna Height (Including M110 Base, mm)	847
Antenna Weight (Including M110 Base, g)	760

Recommend Products

Company Profile

product 360 omnidirectional 55dbi gain 350 390mhz vehicle mounted tactical antenna for public safety vehicles-2

product 360 omnidirectional 55dbi gain 350 390mhz vehicle mounted tactical antenna for public safety vehicles-3

product 360 omnidirectional 55dbi gain 350 390mhz vehicle mounted tactical antenna for public safety vehicles-4

product 360 omnidirectional 55dbi gain 350 390mhz vehicle mounted tactical antenna for public safety vehicles-5

product 360 omnidirectional 55dbi gain 350 390mhz vehicle mounted tactical antenna for public safety vehicles-6

product 360 omnidirectional 55dbi gain 350 390mhz vehicle mounted tactical antenna for public safety vehicles-7

FAQ

Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
