Electrical Specifications |
DB2458-M60V10A |
||
Frequency Range (MHz) |
2400～2500 |
5150～5850 |
|
Polarization |
2×Vertical |
||
Gain (dBi) |
10 |
11 |
|
Electrical Downtilt (°) |
0 |
||
Half Power Beamwidth (°) |
Horizontal: 60 |
Horizontal: 50 |
|
Vertical: 30 |
Vertical: 25 |
||
First Upper Side Lobe Suppression (dB) |
/ |
||
Front-to-Back Ratio (dB) |
≥25 |
||
Input Impedance (Ω) |
50 |
||
Voltage Standing Wave Ratio (VSWR) |
≤2 |
||
Maximum Power (W) |
50 |
||
Mechanical & Environmental Specifications |
||||
Connector Type |
2×N Female |
|||
Connector Position |
Bottom |
|||
Antenna Dimensions (L×W×H: mm) |
230×128×56 |
|||
Packaging Dimensions (mm) |
330×230×160 |
|||
Antenna Weight (kg) |
1 |
|||
Radome Material |
UPVC |
|||
Radome Color |
Gray |
|||
Mechanical Tilt (°) |
0～15 |
|||
Operating Temperature (℃) |
-40～60 |
|||
Extreme Wind Speed (m/s) |
60 |
|||
Pole Diameter (mm) |
35～75 |
|||
Mounting Bracket Model |
MK003 |
|||
