Electrical Specifications |
||||||||||||||
Frequency (MHz) |
698～806 |
806～960 |
1710～1880 |
1880～2170 |
2300～2400 |
2500～2690 |
3300～3700 |
|||||||
Polarization |
±45° |
|||||||||||||
Gain (dBi) |
11.5 |
12 |
15 |
15 |
15 |
15 |
15 |
|||||||
Horizontal 3dB Beamwidth (°) |
≤35 |
≤35 |
≤25 |
≤25 |
≤25 |
≤25 |
≤25 |
|||||||
Vertical 3dB Beamwidth (°) |
≤35 |
≤35 |
≤25 |
≤25 |
≤25 |
≤25 |
≤25 |
|||||||
Front-to-Back Ratio (dB) |
≥20 |
≥20 |
≥23 |
≥23 |
≥23 |
≥23 |
≥23 |
|||||||
Cross-Polarization Ratio (dB) |
≥10 |
|||||||||||||
Input Impedance (Ω) |
50 |
|||||||||||||
VSWR |
≤1.5 |
|||||||||||||
Third-Order Intermodulation (dBm) |
≤-90（@2×43dBm） |
|||||||||||||
Fifth-Order Intermodulation (dBm) |
≤-105（@2×43dBm） |
|||||||||||||
Isolation (dB) |
≥23 |
|||||||||||||
Withstand Power (W) |
200 |
|||||||||||||
Ground Protection |
DC |
|||||||||||||
Mechanical Parameters |
||||||||||||||
Connector Type |
2×NK |
|||||||||||||
Radome Material |
ABS |
|||||||||||||
Dimensions (mm) |
≤750×560×160 |
|||||||||||||
Net Antenna Weight (kg) |
≤8 |
|||||||||||||
Operating Temperature (℃) |
-40～60 |
|||||||||||||
Installation Method |
Wall-mounted or Pole-mounted |
|||||||||||||
