Introduction

The YW-JT-PS304C-48T series is a non - managed POE switch, featuring 48 Gigabit electrical ports. Among them, ports 1 - 48 support the IEEE 802.3af/at standard POE power supply, with a single port POE power of up to 30W. As a POE power supply device, it can automatically detect and identify power - receiving devices that meet the standards and supply power to them through network cables. It can supply power to POE terminal devices such as wireless APs, network cameras, network phones, and video doorphone intercoms via network cables, meeting the needs of network environments requiring high - density POE power supply. It is suitable for hotels, campuses, parks, supermarkets, scenic spots, factory dormitories and SMB small and medium - sized enterprises to build an economical and efficient network.
It is a non - managed model, plug - and - play, no configuration required, and easy to use and maintain.

Features

Gigabit Ports
* Supports "Gigabit PoE Ethernet Port + Gigabit Network Port" combination, enabling flexible networking to meet diverse deployment needs.
* All ports support non-blocking wire-speed forwarding for smoother transmission.
* Compliant with IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control.
Smart PoE Power Supply
* 48× 100/1000Base-T RJ45 PoE+ ports, ideal for surveillance cameras, conference systems, and wireless APs.
* Complies with IEEE 802.3af/at PoE standards, delivering up to 30W per port (auto-detection prevents damage to non-PoE devices).
* Total PoE budget: 800W, ensuring stable power for high-demand scenarios.
Stable & Reliable, Easy Operation
* Energy-efficient design with galvanized steel casing and enhanced heat dissipation for long-term stability.
* Certified with CCC, CE, FCC, and RoHS standards for safety and compliance.
* LED indicators (power, port status, PoE activity) for real-time monitoring.

1000mbps ip30 poe ethernet switch 48 port gigabit unmanaged ethernet hub-3

1000mbps ip30 poe ethernet switch 48 port gigabit unmanaged ethernet hub-5

Product Model	YW-JT - PS304C - 48T
Product Name	48 - port Gigabit POE Switch
Fixed Ports	48*10/100/1000M RJ45 PoE Ports
Network Protocols	IEEE 802.3
		IEEE 802.3i 10BASE - T
		IEEE 802.3u 100BASE - TX
		IEEE 802.3ab 1000BASE - T
		IEEE 802.3z 1000BASE - X
		IEEE 802.3x IEEE 802.3af/at International Standards
Port Characteristics	1 - 48 ports 10/100/1000BaseT (X) Auto - detection, Full/Half - duplex MDI/MDI - X Auto - adaptation
POE Ports	1 - 48 ports support IEEE 802.3af/at Standard POE Power Supply
Forwarding Mode	Store - and - Forward (Full - wire Speed)
Backplane Bandwidth	128Gbps (Non - blocking)
Packet Forwarding Rate	74.40Mpps
MAC Address Table	8K
Packet Forwarding Buffer	4.1M
Twisted - Pair Transmission	10M: Cat3, 4, 5 UTP (≤100 meter)
		100M: Cat5 or later UTP (≤100 meter)
		1000M: Cat5e or later UTP (≤100 meter)
Maximum Single - port/Average Power	30W/15.4W
Total POE Power	MAX 800W
Overall Power Consumption of the Device	Standby Power Consumption: < 30W; Full - load Power Consumption: < 830W
LED Indicators	PW: Power Indicator
		1 - 48: PoE Working Indicators
		PoE Ports: Orange PoE Indicators, Green Network Connection Indicators
Supplied Power	Built - in Power Supply AC: 100 - 240Vac 50 - 60Hz 7.6A Max 830W
Operating Temperature/Humidity	- 10~+55 °C; 5%~90% RH Non - condensation
Storage Temperature/Humidity	- 40~+75 °C; 5%~95% RH Non - condensation
Product Size/Packaging Size	440mm290mm45mm
*(1Outer Carton)**	515mm375mm95mm
Net Weight/Gross Weight (kg)	4.4kg/5.2kg
Installation Method	Rack - mount type (Rack - mount ear accessories provided)
Lightning Protection/Protection Class	Port lightning protection: 6KV 8/20us；
Lightning Protection/Protection Class		Protection class: IP30
Safety Certifications	3C；
Safety Certifications		CE mark, commercial；CE/LVD EN60950；FCC Part 15 Class B；RoHS；
Mean Time Between Failures (MTBF)	＞50,000 hours
Warranty Period	5 years for the main unit (excluding adapters and accessories)

Applications

Highway Electromechanical System Architecture

The electromechanical systems in expressways primarily consist of toll collection, surveillance, and communication subsystems. As the foundational infrastructure, the communication system interconnects all subsystems, serving as the core for service delivery and information-based operations.The expressway's full-network communication adopts a fiber-optic ring network as its backbone, structured around Layer 3 Gigabit Industrial Ethernet Switches supporting fiber-optic ring topology.At each site access point, Layer 2 (or Layer 3) switches establish dedicated subnets for various services. These application subnets are segmented using Virtual Local Area Networks (VLANs) to meet distinct operational requirements.

1000mbps ip30 poe ethernet switch 48 port gigabit unmanaged ethernet hub-6

Industrial Switches for Oil & Gas Field Intelligence
Industrial Ethernet switches enable intelligent monitoring and management of oil/gas fields, enhancing production efficiency and operational safety. These switches withstand extreme field environments—including low/high temperatures, high altitude, humidity, and EMI—while delivering high-reliability, high-performance, stable, and secure network communications.

1000mbps ip30 poe ethernet switch 48 port gigabit unmanaged ethernet hub-7
