Home > Products > Wireless Communication > Microwave Passive Components > Combiner
Channel |
CH1 |
CH2 |
|
Frequency Range (MHz) |
1730 - 1880 |
1920 - 2170 |
|
Insertion Loss (dB) |
≤0.6 |
||
In - band Ripple (dB) |
≤0.5 |
||
Port Isolation (dB) |
≥80 |
||
VSWR |
≤1.3 |
||
Impedance (Ω) |
50 |
||
Third - order Intermodulation (dBc) |
≤ - 150@43dBm×2 |
||
Fifth - order Intermodulation (dBc) |
≤ - 165@43dBm×2 |
||
Interface Type |
DIN - F/4.3-10/N |
||
Power Capacity (W) |
Average Power Capacity ≥500, Peak Power Capacity ≥1500 |
||
Dimension（mm） |
151*119*40 |
||
