80kw 96kw 100kva 120kva Online Double Conversion UPS Uninterrupted Power Supply Backup for Servers Lightning Competitive Price

80kw 96kw 100kva 120kva Online Double Conversion UPS Uninterrupted Power Supply Backup for Servers Lightning Competitive Price

Description

[email protected]

Description

Product Description

Yoongwin Situation Awareness Technology Co., Ltd., founded in 2007 in Nanjing Economic and Technological Development Zone with a registered capital of RMB 60.06 million, controls eight medium - sized tech enterprises. Its main business spans thin - film circuits, antenna & feeder products, etc., and it's involved in industrial Internet security and electromagnetic space protection.
As a member of multiple associations, it holds dual - software and ISO2700 info security certifications. With over 100 patents, it was recognized as a Nanjing Gazelle Enterprise from 2020 - 2022, indicating continuous growth.

80kw 96kw 100kva 120kva Online Double Conversion UPS Uninterrupted Power Supply Backup for Servers Lightning Competitive Price details

Product Detail

Model	YWHQ3110GR(L)	YWHQ3115GR(L)	YWHQ3120GR(L)
Capacity	10kVA	15kVA	20kVA
Input
Rated Voltage	380Vac (Three - phase + N)
Voltage Range	190Vac - 520Vac @50% load; 305Vac - 478Vac @100% load
Frequency Range	46Hz - 54Hz @50Hz system; 56Hz - 64Hz @60Hz system
Power Factor	≥0.99@100% load
Output
Output Voltage	208/220/230/240Vac
Voltage Accuracy	±1%
Frequency Range (Synchronous Range)	46Hz - 54Hz or 56Hz - 64Hz
Frequency Range (Battery Mode)	50Hz ± 0.1Hz or 60Hz ± 0.1Hz
Power Factor	Standard 0.8 (Optional 0.9)
Current Peak Ratio	3:1
Total Harmonic Distortion (THD)	≤2% @ 100% linear load; ≤5% @ 100% non - linear load
Overload Capacity
Utility Mode	105% - 110%: 10 minutes; 110% - 130%: 1 minute; >130%: 1 second
Battery Mode	105% - 110%: 30 seconds; 110% - 130%: 10 seconds; >130%: 1 second
Transfer Time
Utility → Battery	0 ms
Inverter → Bypass	0 ms
Efficiency
Inverter Mode	>90%
Battery
Battery Model	12V / 7Ah
Battery Quantity	Preset 16 sections (Adjustable from 16 - 20 sections)	Preset 2×16 sections (Adjustable from 16 - 20 sections)
Charging Current	1A ± 10%	2A ± 10%
Charging Voltage	218.4Vdc ± 1%
Physical Characteristics
Dimensions Depth x Width x Height (mm)	UPS main unit: 668 x 482.6 x 133(3U)	UPS main unit: 668 x 482.6 x 266(6U)
Dimensions Depth x Width x Height (mm)		Battery cabinet: 580 x 482.6 x 133(3U)	Battery cabinet: 580 x 482.6 x 133(3U) x 2 pcs
Net Weight (kg)	UPS main unit: 22; Battery cabinet: 63	UPS main unit: 45; Battery cabinet: 63 x 2 pcs
Environmental Conditions
Operating Environment	Relative humidity 0 - 95% and temperature 0 - 40°C (non - condensing)
Noise Level	< 60dB(A) @ 1m	< 65dB(A) @ 1m
Management
Intelligent RS - 232 or USB	Support Windows® 2000/2003/XP/Vista/2008/7/8, Linux and MAC
Optional SNMP	Support power management by SNMP manager and web browser
