Electrical Specifications |
||
Frequency (MHz) |
820～960×2 |
|
Polarization |
±45° |
|
Gain (dBi) |
16.5 |
|
Electrical Downtilt (°) |
0～10 |
|
Electrical Downtilt Accuracy (°) |
±1 |
|
Horizontal 3dB Beamwidth (°) |
65±8 |
|
Vertical 3dB Beamwidth (°) |
≥12 |
|
Front-to-Back Ratio (dB) |
≥25 |
|
Cross-Polarization Ratio (dB) |
≥15 (≥10 within ±60°) |
|
Upper Side Lobe Suppression (dB) |
≤-14 |
|
Input Impedance (Ω) |
50 |
|
VSWR (Voltage Standing Wave Ratio) |
≤1.5 |
|
Third-Order Intermodulation (dBm) (@2×20W) |
≤-97 |
|
Isolation (dB) |
≥25 |
|
Maximum Power (W) |
200 |
|
Ground Protection |
DC Ground |
|
Mechanical Parameters |
||
Connector Type |
4×7/16 |
|
Connector Location |
Bottom |
|
Radome Material |
UPVC |
|
Dimensions (mm) |
Φ380×1350 |
|
Antenna Weight (kg) |
≤30 |
|
Maximum Wind Speed (m/s) |
60 |
|
Operating Temperature (℃) |
-40～+60 |
|
Electrical Tilt Control Method |
Manual Electrical Tilt |
|
