Electrical Indicators |
M2D2458-90V10DF |
|
Frequency Range (MHz) |
2400～2500 |
|
Polarization |
2×Vertical |
|
Gain (dBi) |
10 |
|
Electrical Downtilt (°) |
/ |
|
Half Power Beamwidth (°) |
Horizontal: 90 |
|
Vertical: 30 |
||
Isolation (dB) |
≥20 |
|
Front-to-Back Ratio (dB) |
≥20 |
|
Input Impedance (Ω) |
50 |
|
Voltage Standing Wave Ratio |
≤2 |
|
Maximum Power (W) |
50 |
|
Mechanical and Environmental Indicators |
Mechanical and Environmental Indicators |
|
Connector Type |
2×N Female |
|
Connector Position |
Back |
|
Antenna Size (Length×Width×Thickness: mm) |
260×190×30 |
|
Antenna Weight (kg) |
Approx. 1.2 |
|
Radome Material |
ABS |
|
Radome Color |
White |
|
Mechanical Adjustable Tilt (°) |
0～30 |
|
Operating Temperature (℃) |
-40～60 |
|
Ultimate Wind Speed (m/s) |
60 |
|
Boom Diameter (mm) |
35～50 |
|
Mounting Part Model |
MK004 L-shaped Steel Clamp |
|
