Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device
Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device

Dual Band WiFi Antenna 2.4GHz 5GHz 2dBi Gain Vertical Polarization Connector for Router IoT Device

Get a Quote Contact Us
  • Description
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-1

[email protected]
Inquiry
Product Description
Product Detail
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-2
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-3
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-4
Product Name
Dual-band Omnidirectional Antenna
Frequency Range (MHz)
2400 - 2483 / 5150 - 5850
Bandwidth (MHz)
83 / 700
Polarization Mode
Vertical
Gain (dBi)
2
Input Impedance (Ω)
50
Voltage Standing Wave Ratio
≤2
Maximum Power (W)
20
Connector Type
SMA Male or Customized by User
Antenna Size (mm)
φ34×108
Lead Length (cm)
20 or Customized by User
Antenna Weight (kg)
Approx. 0.1
Mounting Method
Nut Locking
Recommend Products
Company Profile
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-5
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-6
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-7
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-8
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-9
product dual band wifi antenna 24ghz 5ghz 2dbi gain vertical polarization connector for router iot device-10
FAQ
Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
