YWDSPBG698-2700X-7i-80-4310-1 |
||||
Electrical specifications |
||||
Frequency range (MHz) |
698-960 |
1710-2700 |
||
Polarization |
±45° |
|||
Gain(dBi) |
7 |
7 |
||
Horizontal half-power beam width (°) |
80±20 |
|||
Vertical half-power beam width(°) |
70 |
60 |
||
Front-To-Back Ratio |
≥15 |
|||
Isolation (dB) |
10 |
|||
VSWR |
≤1.8 |
|||
PIM, 3rd Order (dBc) |
≤-150 (2 × 43 dBm carrier) |
|||
Impedance(Ω) |
50 |
|||
Maximum input power(W) |
50 |
|||
Lightning protection |
DC ground |
|||
Mechanical specifications |
||||
Connector |
2 × 4.3-10 Female |
|||
Dimensions (H x W x D) (mm) |
300×250×100 |
|||
Net weight (with installation kit) (kg) |
≤1.8 |
|||
Application scen |
Indoor |
|||
Radome materia |
UV ABS |
|||
Operating temperature (℃) |
-40 to +55 |
|||
Mounting Kit |
On-wall |
|||
