High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage

High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage

Get a Quote Contact Us
  • Description
11dbi panel antenna with robust 190x190mm design for reliable coverage572-1

[email protected]
Inquiry
Product Description
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage manufacture
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage factory
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage supplier
High Gain Stable Professional Grade 10/11dBi Panel Antenna with Robust 190x190mm Design for Reliable Coverage supplier
Product Detail
Product Name
Directional Miniature Panel Antenna
Electrical Indicators
YW-DF2458-60V10D
Frequency Range (MHz)
2400～2500
5150～5850
Polarization
Vertical
Vertical
Gain (dBi)
10
11
Electrical Downtilt (°)
0
0
Half Power Beamwidth (°)
Horizontal: 60
Horizontal: 50
Vertical: 30
Vertical: 25
First Upper Side Lobe Suppression (dB)
/
/
Front-to-Back Ratio (dB)
≥28
≥28
Input Impedance (Ω)
50
50
Voltage Standing Wave Ratio
≤2
≤2
Maximum Power (W)
50
50
Mechanical and Environmental Indicators
Connector Type
N Female
Lead Length
/
Antenna Size (Length×Width×Thickness: mm)
190×190×40
Antenna Weight (kg)
1
Radome Material
ABS
Radome Color
White
Mechanical Adjustable Tilt (°)
0～30
Operating Temperature (℃)
-40～60
Ultimate Wind Speed (m/s)
60
Boom Diameter (mm)
35～50
Mounting Part Model
MK004C L-shaped Steel Clamp
