| Rated voltage | 250VAC, 50/60Hz |
| Operating frequency | DC to 400Hz |
| Rated currents | 1 to 30A @40℃ max |
| High potential test voltage | L→N: 1100VDC for 2s; L, N→PE: 2250VDC for 2s |
| Temperature range | -25℃ to +100℃ (25/100/21) |
| Certified to | UL1283, EN60939 |
| Filter model | Rated current@40°C（A） | Leakage current@250VAC/50Hz（mA） | Input/Output Connections | Weight（g） |
| DL20060 - 1-06 | 1 | 0.66 | 6.3×0.8 | 95 |
| DL20060 - 3-06 | 3 | 0.66 | 6.3×0.8 | 105 |
| DL20060 - 6-06 | 6 | 0.66 | 6.3×0.8 | 105 |
| DL20060 - 10-06 | 10 | 0.66 | 6.3×0.8 | 155 |
| DL20060 - 12-06 | 12 | 0.66 | 6.3×0.8 | 160 |
| DL20060 - 16-.. | 16 | 0.66 | 6.3×0.8、M4 | 235 |
| DL20060 - 20-.. | 20 | 0.66 | 6.3×0.8、M4 | 450 |
| DL20060 - 30-08 | 30 | 0.79 | M4 | 850 |
| DL20060S - 1-06 | 1 | 0.07 | 6.3×0.8 | 95 |
| DL20060S - 3-06 | 3 | 0.07 | 6.3×0.8 | 105 |
| DL20060S - 6-06 | 6 | 0.07 | 6.3×0.8 | 105 |
| DL20060S - 10-06 | 10 | 0.07 | 6.3×0.8 | 155 |
| DL20060S - 12-06 | 12 | 0.07 | 6.3×0.8 | 160 |
| DL20060S - 16-.. | 16 | 0.07 | 6.3×0.8、M4 | 235 |
| DL20060S - 20-.. | 20 | 0.07 | 6.3×0.8、M4 | 450 |
| DL20060S - 30-08 | 30 | 0.07 | M4 | 850 |
| DL20060N - 1-06 | 1 | 0 | 6.3×0.8 | 95 |
| DL20060N - 3-06 | 3 | 0 | 6.3×0.8 | 105 |
| DL20060N - 6-06 | 6 | 0 | 6.3×0.8 | 105 |
| DL20060N - 10-06 | 10 | 0 | 6.3×0.8 | 155 |
| DL20060N - 12-06 | 12 | 0 | 6.3×0.8 | 160 |
| DL20060N - 16-.. | 16 | 0 | 6.3×0.8、M4 | 235 |
| DL20060N - 20-.. | 20 | 0 | 6.3×0.8、M4 | 450 |
| DL20060N - 30-08 | 30 | 0 | M4 | 850 |
