Indoor Use 6.5/7.5/8.0dBi Gain N-Female Connector 2g 3g 4g LTE All Frequency Panel Antenna Wall Antenna

Indoor Use 6.5/7.5/8.0dBi Gain N-Female Connector 2g 3g 4g LTE All Frequency Panel Antenna Wall Antenna

Description

80dbi gain n female connector 2g 3g 4g lte all frequency panel antenna wall antenna-1

[email protected]

Description

Product Description

Indoor Use 6.5/7.5/8.0dBi Gain N-Female Connector 2g 3g 4g LTE All Frequency Panel Antenna Wall Antenna manufacture

Product Detail

Product Name

Indoor Directional Unipolar Wall-Mounted Antenna

Electrical Performance

Operating Frequency Band (MHz)

880-960

1710-1850

1885-1915

2010-2025

2300-2400

2400-2483.5

2515-2675

Polarization Mode

H/V

Gain (dBi)

≥6.5

≥7.5

≥8

Horizontal Plane Lobe Width (°)

90±10

75±10

Vertical Half-Power Beamwidth (°)

Front-to-Back Ratio (dB)

≥12

≥15

Polarization Isolation (dB)

Voltage Standing Wave Ratio (VSWR)

≤1.5

Third-Order Intermodulation (dBm@2*2W)

≤-85

Average Power Tolerance (W)

≥50

Mechanical Performance

Antenna Enclosure Material

ABS/PS

Connector Type

N-type Female

Connector Lead Length (mm)

≥250

Antenna Dimension (mm)

275*148*59

Packaging Dimension (mm)

312*155*70

Antenna Weight (kg)

0.4

Operating Temperature (℃)

-30~+45

Storage Temperature (℃)

-40~+55

Recommend Products

Company Profile

Indoor Use 6.5/7.5/8.0dBi Gain N-Female Connector 2g 3g 4g LTE All Frequency Panel Antenna Wall Antenna details

Indoor Use 6.5/7.5/8.0dBi Gain N-Female Connector 2g 3g 4g LTE All Frequency Panel Antenna Wall Antenna factory

FAQ

Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
