Electrical Specifications |
||||
Operating Frequency Band (MHz) |
820~960 |
1710~2170 |
||
Polarization (°) |
Vertical Polarization |
±45° |
||
Voltage Standing Wave Ratio (VSWR) of Each Radiating Port |
≤1.4 |
|||
Third-Order Intermodulation (dBm, @2×37 dBm) |
≤-97 |
|||
Average Power Handling Capacity (W) |
150 |
|||
Isolation (dB) |
≥25 |
|||
Horizontal Half-Power Beamwidth (°) |
60±10 |
65±10 |
||
Vertical Half-Power Beamwidth (°) |
35±10 |
25±10 |
||
Gain (dBi) |
9.5-12.5 |
12.5-15.5 |
||
Cross-Polarization Ratio (dB, Axial) |
≥15 |
|||
Cross-Polarization Ratio (dB, Within ±30°) |
≥10 |
|||
Front-to-Back Ratio (dB) |
≥23 |
|||
Impedance (Ω) |
50 |
|||
Mechanical Specifications |
||||
Interface Model |
2×N-Female |
|||
Antenna Dimensions (mm) |
545×545×205 |
|||
Packaging Dimensions (mm) |
585×570×220 |
|||
Antenna Weight (Kg) |
5.4 |
|||
Radome Material |
Weather-Resistant PP (Polypropylene) |
|||
Maximum Wind Speed (km/h) |
200 |
|||
Ambient Temperature (°C) |
Operating Temperature: -40~+70; Extreme Temperature: -55~+75 |
|||
Protection Level |
Not lower than IP55 Requirements |
|||
Installation Method |
Bracket Mounting |
|||
Adjustable Azimuth Angle |
Mechanical Adjustment of Pitch Angle, Single Sector ±45° |
|||
Lightning Protection |
DC Grounding |
|||
