Electrical Specification |
||
Frequency Range (MHz) |
162-175 |
|
Polarization |
Vertical |
|
VSWR |
＜1.5 |
|
Gain (dBi) |
5 |
|
HPBW (Horizontal) |
360° |
|
HPBW (Vertical) |
35° |
|
Max Input power (W) |
150 |
|
Impedance （Ω） |
50 |
|
Lighting Protection |
DC-Ground |
|
Connector |
N-Female |
|
Height (mm) |
2950±10 |
|
Weight (Kg) |
≤4.5 |
|
Wind Area (㎡) |
0.12 |
|
Wind load (N) |
160 |
|
Material |
Radome: Polyurethane-coated glass fibre |
|
Mounting bracket: Sea water resistant Zinc-coated Steel |
||
Radome Colour |
White |
|
Mounting |
On 40-70 mm dia. mast tube |
|
