Product Description

1.High Gain Wideband Performance: Delivers exceptional 8.5-9dBi gain across the entire 1420-1530MHz band. Provides superior signal strength and clarity for long-range communications in satellite and military applications.

2.Precision 360° Omnidirectional Coverage: Ensures consistent signal reception from all directions with optimized 9° vertical beamwidth. Maintains reliable connectivity for rotating platforms and mobile applications without signal dropouts.

3.Military-Grade Environmental Protection: Features salt spray corrosion resistance and operates reliably from -40℃ to +70℃.Withstands 95% humidity conditions, making it ideal for coastal and extreme environment deployments.

4.High-Power 100W Capacity: Professional N-Type female connector supports high-power transmission requirements. Ensures clear signal integrity over long distances in critical communication systems.

5.Professional Fiberglass Construction: 1.5-meter rugged design built for long-term outdoor deployment. The optimized structural design provides excellent durability while maintaining superior electrical performance.

Product Detail

Antenna Characteristics
Frequency Range	1420～1530 MHz
Impedance	50 Ω
Polarization	Vertical Polarization
Beamwidth	Horizontal: 360°; Elevation: ≥9°
Voltage Standing Wave Ratio (VSWR)	≤2.0
Antenna Gain	≥9 dBi (1470~1530 MHz); ≥8.5 dBi (1420~1470 MHz)
Maximum Power	100 W
Connector Type	N-Type Female Connector
Operating Environment
Operating Temperature	-40℃～+70℃
Storage Temperature	-55℃～+85℃
Humidity	95% (non-condensing)
Special Protection	Salt Spray Corrosion Resistance
