Screen |
2.4 inch touch panel 320*240 |
USB Port |
Type-C.USB3.0,support data transfer |
Button |
Power Key,Reset(Hidden) |
eSIM |
Buill-in Thales/Linksfield eSIMchip |
Card slot |
One 4FF(Nano)UICC/USIM,push slot.. |
Battery |
4500mAh Li-on un-removoble |
Size |
131.5*68.5*13.7mm |
Charger Power |
5V 3A |
Weight |
150g |
Cellular |
5G/LTE |
Qualcomm Snapdragon X62 |
|
Standard compliant:3GPP Release 16(both LTE and 5G) |
|||
EAU version NR Sub-6:n1/3/5/7/8/20/28/38/40/41/75/76/77/78/79 LTE:B1/3/5/7/8/20/28/32/38/40/41/42/43 WCDMA:B1/2/5/8 NA version NR Sub-6:n2/5/7/12/14/25/30/48/41/70/66/71/77/78 LTE:B2/4/5/7/12/13/29/30/66/71/41/46/48 |
|||
Modulation: Sub-6 UL:256QAM,DL:256QAM LTE DL:256QAM,DL:256QAM |
|||
MIMO: Sub-6 DL:4x4,UL:1x1 LTE DL:4X4,UL:1X1 |
|||
Antenna(both LTEand 5G):8 built-in laser-engraved |
|||
antennas |
|||
Peak data rate: Sub-6:DL3.5Gbps.UL 900Mbps |
|||
Peak data rate:Sub-6:DL3.5Gbps.UL 900Mbps |
|||
Wi-Fi |
Qualcomm Atheros WCN6856 |
||
Standard compliant:IEEE 802.11 a/b/g/n/ac/l1ax |
|||
2.4 GHz(2x2 MIMO)+5.8G band(2×2MIMO) |
|||
AX3600 |
|||
Bluetooth |
Support |
||
Temperature |
Operating:0℃ to 45℃ |
||
Storage:0℃ to 45℃ |
|||
Humidity |
Operating Humidity:5 to 95%RH |
||
Storage Humidity:5 to 95%RH |
|||
Non-condensing |
|||
System Features |
Web UI/Multiple language supported |
SMS/Quota/APN/PIN Management |
|
Network Selection |
|
Data Usage/Statistic |
|
DHCP Server |
|
NAT |
|
IP Firewall |
|
Proxy DNS |
|
Security-SIM Lock and Secure boot features. |
|
Firewall-DMZ/MAC Filter/IP Filter/URL Filter/Port Filter |
|
Wi-FiAP Features |
802.11 a/b/g/n/ac/ax 2.4GHz+5.8GHz |
MU-MIMO |
|
Band Steering |
|
Auto Channel Select (ACS) |
|
Wi-Fi Enabled Device#:up to 32 |
|
Hidden SSID |
|
Security Modes:WPA/WPA2 PSK,&WPA/WPA2 mixed mode,WPA3 |
|
Access Control:STA blacklist/white list |
|
WPS:Pin and PBC,WPS2.0 |
