Electrical Specifications |
||
Operating Frequency Band (MHz) |
2×(1710~2170) |
|
Polarization (°) |
±45° |
|
Voltage Standing Wave Ratio (VSWR) of Each Radiating Port |
≤1.4 |
|
Third-Order Intermodulation (dBm, @2×37 dBm) |
≤-97 |
|
Average Power Handling Capacity (W) |
150 |
|
Isolation (dB) |
≥25 |
|
Horizontal Half-Power Beamwidth (°) |
25±10 |
|
Vertical Half-Power Beamwidth (°) |
65±10 |
|
Gain (dBi) |
13-15 |
|
Cross-Polarization Ratio (dB, Axial) |
≥15 |
|
Cross-Polarization Ratio (dB, Within ±15°) |
≥10 |
|
Front-to-Back Ratio (dB) |
≥23 |
|
Impedance (Ω) |
50 |
|
Mechanical Specifications |
||
Interface Model |
4×N-Female |
|
Antenna Dimensions (mm) |
430×428×130 |
|
Packaging Dimensions (mm) |
475×460×160 |
|
Antenna Weight (Kg) |
3.1 |
|
Radome Material |
Weather-Resistant PP (Polypropylene) |
|
Maximum Wind Speed (km/h) |
200 |
|
Ambient Temperature (°C) |
Operating Temperature: -40~+70; Extreme Temperature: -55~+75 |
|
Protection Level |
Not lower than IP55 Requirements |
|
Installation Method |
Bracket Mounting |
|
Adjustable Azimuth Angle |
Mechanical Adjustment of Pitch Angle, Single Sector ±45° |
|
Lightning Protection |
DC Grounding |
|
