Electrical Specifications |
M4D58-30VH14D |
|
Frequency Range (MHz) |
5150～5850 |
|
Polarization |
2×Vertical + 2×Horizontal |
|
Gain (dBi) |
14 |
|
Electrical Down-tilt (°) |
0 |
|
Half-power Beamwidth (°) |
H-plane: 30 |
|
E-plane: 26 |
||
First Upper Side Lobe Suppression (dB) |
/ |
|
Front-to-Back Ratio (dB) |
≥25 |
|
Input Impedance (Ω) |
50 |
|
Voltage Standing Wave Ratio (VSWR) |
≤2 |
|
Maximum Power (W) |
50 |
|
Lightning Protection |
DC Grounding |
|
Mechanical & Environmental Specifications |
||
Connector Type |
4×N Female |
|
Connector Position |
Rear |
|
Antenna Dimensions (L×W×H: mm) |
190×190×40 |
|
Antenna Weight (kg) |
Approximately 1 |
|
Radome Material |
ABS |
|
Radome Color |
White |
|
Mechanical Adjustable Tilt (°) |
0～30 |
|
Operating Temperature (℃) |
-40～60 |
|
Ultimate Wind Speed (m/s) |
60 |
|
Mast Diameter (mm) |
35～50 |
|
