Home > Products > Others > Filters > Power Filter
| Rated Voltage | 440/250VAC | ||
| Operating Frequency | 50/60Hz | ||
| Rated Current | 100A - 800A | ||
| Test Voltage (1 min) | 1500 VDC (line/line); 2250 VDC (line/ground) | ||
| Climatic Category | 40/085/21 |
| Model |
Rated Current （A） |
Ground Capacitance（nF） | Discharge Resistance（KΩ） |
| DL - 100EBK1 | 100 | 100 | 220 |
| DL - 150EBK1 | 150 | 100 | 220 |
| DL - 200EBK1 | 200 | 100 | 220 |
| DL - 300EBK3 | 300 | 2.1μF | 660 |
| DL - 400EBK3 | 400 | 2.1μF | 660 |
| DL - 600EBK3 | 600 | 2.1μF | 660 |
| DL - 800EBK3 | 800 | 2.1μF | 660 |
