| Rated Voltage | 480/275VAC |
| Operating Frequency | 50/60Hz |
| Rated Current | 5A - 1000A |
| Test Voltage (1 min) | 1500 VDC (line/line); 2250 VDC (line/ground) |
| Climatic Category | 40/085/21 |
| Model |
Rated Current （A） |
Ground Capacitance（nF） |
Discharge Resistance（MΩ） R1-3 R0 |
|
| DL - 5EBK5 | 5 | 200 | 1.5 | 0.68 |
| DL - 10EBK5 | 10 | 200 | 1.5 | 0.68 |
| DL - 16EBK5 | 16 | 200 | 1.5 | 0.68 |
| DL - 25EBK5 | 25 | 200 | 1.5 | 0.68 |
| DL - 35EBK5 | 35 | 200 | 1.5 | 0.68 |
| DL - 50EBK5 | 50 | 320 | 1.5 | 0.68 |
| DL - 65EBK5 | 65 | 320 | 1.5 | 0.68 |
| DL - 80EBK5 | 80 | 320 | 1.5 | 0.68 |
| DL - 100EBK5 | 100 | 320 | 1.5 | 0.68 |
| DL - 130EBK5 | 130 | 690 | 1.5 | 0.68 |
| DL - 160EBK5 | 160 | 690 | 1.5 | 0.68 |
| DL - 200EBK5 | 200 | 690 | 1.5 | 0.68 |
| DL - 1000EBK5 | 1000 | 940 | 1.5 | 0.68 |
