Product Detail

Hardware
CPU	1.3GHz Dual-core MT7981B
RAM	DDR4 1GB
Flash	eMMC 8GB
Ethernet	One(1) 2.5Gbps WAN Ethernet Port Three(3) 1Gbps LAN Ethernet Ports
Wireless Technology	802.11b/g/n 300Mbps MIMO Technology
Interfaces	One(1) Power Adapter Port Two(2) Nano SIM Slots One(1) USB-C Debug Port
Buttons	One(1) WPS Button One(1) Power Button One(1) Reset Button
LED Indicators	One(1) System indicator One(1) 5G indicator One(1) 4G indicator One(1) WiFi indicator
Antennas	Built-in 5G/LTE primary antenna Built-in 5G/LTE secondary antenna Built-in Wi-Fi 2.4GHz/5GHz antennas
Operating Environment	0~40°C, 10%～90% non-condensing
Storage Environment	-40~70°C, 5%～95% non-condensing
Physical Size	100100200 mm
Weight	750g
Power Supply	12V/1.5A

Wi-Fi
Standards	2.4GHz	IEEE 802.11b/g/n/ax
Standards		5GHz	IEEE 802.11a/n/ac/ax
Supported Rates	802.11b	1/2/5.5/11Mbps
		802.11a/g	6/9/12/18/24/36/48/54Mbps
		802.11n	MCS0~7
		802.11ac	MCS0~11
		802.11ax	MCS0~11
2.4GHz	Peak PHY Rates	574Mbps
		Channels	Ch1~13
		Spatial Streams	2T2R
		Channelization	20/40/80MHz
		Client Capacity	256
5GHz	Peak PHY Rates	2402Mbps
		Channels	Ch36~64, 100-144, 149~165
		Spatial Streams	2T3R
		Channelization	20/40/80/160MHz
		Client Capacity	256

Celluar
Module	Model	RM520-GL
		Area	Global
		Chipset	Qualcomm Snapdragon SDX62
5G NR	5G NR	3GPP Release 16 NSA/SA operation, Sub-6 GHz
		Sub-6 NSA Band	n1/2/3/5/7/8/12/13/14/18/20/25/26/28/39/30/38/40/41/48/66/70/71/75/76/77/78/79
		Sub-6 SA Band	n1/2/3/5/7/8/12/13/14/18/20/25/26/28/39/30/38/40/41/48/66/70/71/75/76/77/78/79
		Max. Sub-6 BW	120MHz
		Sub-6 CA	FDD+FDD,TDD+TDD,FDD+TDD DL2CA/UL 2CA
		DL 4x4 MIMO	n1/2/3/5/7/25/30/38/40/48/66/70/77/78/79
		UL 2x2 MIMO	n38/41/48/77/78/79
LTE	LTE Category	DL Cat19 / UL Cat18
		LTE-FDD Band	B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71
		LTE-TDD Band	B34/38/39/40/41/42/43/48
		LTE LAA Band	B46
		DL 4x4 MIMO	B1/2/3/4/7/25/30/38/40/41/42/43/48/66
UMTS	WCDMA Band	B1/2/4/5/8/19
Max. PHY Rates	5G SA Sub-6 Max.	DL 2.4 Gbps; UL 900 Mbps
		5G NSA Sub-6 Max.	DL 3.4 Gbps; UL 550 Mbps
		LTE Max.	DL 1.6 Gbps; UL 200 Mbps
		WCDMA Max.	DL 42 Mbps; UL 5.76 Mbps
