IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor
IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor

IEC 60289 Compliant 7% 14% Impedance Harmonic Suppression 450VAC Low Voltage 3-Phase Series Reactor

Get a Quote Contact Us
  • Description
product iec 60289 compliant 7 14 impedance harmonic suppression 450vac low voltage 3 phase series reactor-1

[email protected]
Inquiry
Product Description
Product Detail
Capacitor voltage
450V
Reactive power rate
6% 7% 12% 13% 14%
Reactor capacity
0.3~14KVAR
Protection level
IP00
Withstand voltage
3000V
Capacitor capacity
2~100KVAR
Inductance
0.5~57.4 mH
Insulation class
F/H class
REACTOR MODEL
MATCHING CAPACITOR CAPACITY
(kVar)
REACTOR CAPACITY
(kVar)
INDUCTANCE
(mH)
OVERALL DIMENSIONS
L
W
H
CKSG-0.35/0.48 - 7%
5
0.35
10.3
150
90
150
CKSG-0.7/0.48 - 7%
10
0.7
5.14
180
150
155
CKSG-1.05/0.48 - 7%
15
1.05
3.43
180
150
155
CKSG-1.4/0.48 - 7%
20
1.4
2.57
210
150
192
CKSG-1.75/0.48 - 7%
25
1.75
2
240
150
210
CKSG-2.1/0.48 - 7%
30
2.1
1.7
240
157
230
CKSG-2.8/0.48 - 7%
40
2.8
1.3
240
167
230
CKSG-3.5/0.48 - 7%
50
3.5
1
260
167
250
CKSG-4.2/0.48 - 7%
60
4.2
0.9
260
185
260
CKSG-4.9/0.48 - 7%
70
4.9
0.7
300
175
270
CKSG-5.6/0.48 - 7%
80
5.6
0.6
300
175
290
CKSG-6.3/0.48 - 7%
90
6.3
0.6
300
185
290
CKSG-7.0/0.48 - 7%
100
7
0.5
300
195
290
CKSG-0.3/0.525 - 14%
2
0.3
57.4
150
90
150
CKSG-0.45/0.525 - 14%
3
0.45
38.2
150
90
150
CKSG-0.6/0.525 - 14%
4
0.6
28.7
180
150
155
CKSG-0.9/0.525 - 14%
6
0.9
19.1
180
150
155
CKSG-1.4/0.525 - 14%
10
1.4
12.3
210
150
192
CKSG-1.8/0.525 - 14%
13
1.8
9.6
240
150
210
CKSG-2.1/0.525 - 14%
15
2.1
8.2
240
157
230
CKSG-2.8/0.525 - 14%
20
2.8
6.1
240
157
230
CKSG-3.5/0.525 - 14%
25
3.5
4.9
300
170
250
CKSG-4.2/0.525 - 14%
30
4.2
4.1
300
175
250
CKSG-5.6/0.525 - 14%
40
5.6
3.1
300
175
290
CKSG-7.0/0.525 - 14%
50
7
2.5
300
197
290
CKSG-8.4/0.525 - 14%
60
8.4
2
300
214
290
CKSG-9.8/0.525 - 14%
70
9.8
1.8
360
197
310
CKSG-11.2/0.525 - 14%
80
11.2
1.5
360
197
330
CKSG-12.6/0.525 - 14%
90
12.6
1.4
360
217
330
CKSG-14/0.525 - 14%
100
14
1.2
360
217
330
REACTOR MODEL
INSTALLATION DIMENSIONS
A
B
MOUNTING HOLE
CKSG-0.35/0.48 - 7%
85
70
7×12
CKSG-0.7/0.48 - 7%
100
95
10×20
CKSG-1.05/0.48 - 7%
100
95
10×20
CKSG-1.4/0.48 - 7%
100
95
10×20
CKSG-1.75/0.48 - 7%
150
95
10×20
CKSG-2.1/0.48 - 7%
150
110
10×20
CKSG-2.8/0.48 - 7%
150
113
10×20
CKSG-3.5/0.48 - 7%
150
113
10×20
CKSG-4.2/0.48 - 7%
150
134
10×20
CKSG-4.9/0.48 - 7%
150
124
10×20
CKSG-5.6/0.48 - 7%
150
124
10×20
CKSG-6.3/0.48 - 7%
150
134
10×20
CKSG-7.0/0.48 - 7%
150
144
10×20
CKSG-0.3/0.525 - 14%
85
70
7×12
CKSG-0.45/0.525 - 14%
85
70
7×12
CKSG-0.6/0.525 - 14%
100
95
10×20
CKSG-0.9/0.525 - 14%
100
95
10×20
CKSG-1.4/0.525 - 14%
100
95
10×20
CKSG-1.8/0.525 - 14%
150
95
10×20
CKSG-2.1/0.525 - 14%
150
110
10×20
CKSG-2.8/0.525 - 14%
150
110
10×20
CKSG-3.5/0.525 - 14%
150
110
10×20
CKSG-4.2/0.525 - 14%
150
124
10×20
CKSG-5.6/0.525 - 14%
150
124
10×20
CKSG-7.0/0.525 - 14%
150
146
10×20
CKSG-8.4/0.525 - 14%
200
164
10×20
CKSG-9.8/0.525 - 14%
200
146
10×20
CKSG-11.2/0.525 - 14%
200
146
10×20
CKSG-12.6/0.525 - 14%
200
166
10×20
CKSG-14/0.525 - 14%
200
166
10×20
