YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage
YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage

YW-QE2400D 2.4GHz Single Band Ceiling Antenna 3dBi Gain Optimized for WiFi and IoT Device Coverage

Get a Quote Contact Us
  • Description
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-1

[email protected]
Inquiry
Product Description
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-2
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-3
Technical Indicators
YW-QE2400D
Frequency Range (MHz)
2400～2500
Bandwidth (MHz)
100
Polarization Mode
Vertical
Gain (dBi)
3
Input Impedance (Ω)
50
Voltage Standing Wave Ratio
≤1.5
Maximum Power (W)
20
Connector Type
N Female or Customized by User
Antenna Size (mm)
φ124×47
Lead Length (cm)
30 or Customized by User
Antenna Color
White
Antenna Weight (kg)
0.15
Mounting Method
Ceiling Mounted
Antenna Weight (kg)
0.3
Mounting Method
Ceiling Mounted
Recommend Products
Company Profile
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-4
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-5
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-6
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-7
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-8
product yw qe2400d 24ghz single band ceiling antenna 3dbi gain optimized for wifi and iot device coverage-9
FAQ
Q: Are you a manufacturer or a trading company? A: We have been professional antenna manufacturer for 18 years. Q: Have gps gsm combo antenna 100% assembles well in stock? A: No, all gps gsm combo antenna will be newly assembled according to your orders including the samples. Q: Could I use my own LOGO or design on goods? A: Yes, customized logo and design on mass production are available. Q: What's the payment term? A: T/T, AliPay,Paypal,Afterpay,Klarna etc. Q:What certifications do you have? A:Certified by FCC, CE, RoHS,ISO available upon request. Q: Where is your factory located? Can I visit your factory? A: Factory address: 2nd Floor, Building D4-1, Hongfeng Science and Technology Park, Nanjing Economic and Technological Development Zone, Jiangsu Province. Just call us, we will pick you up with no delay.
